MikroTik GPERx6 Switch - CSS606-1G-2Gi-3S+OUT
MikroTik
||||MikroTik GPERx6 Switch - CSS606-1G-2Gi-3S+OUT
At a glance:
- 3 x 10G SFP+
- 3 x Gigabit Ethernet Ports
- Heavy duty IP66 enclosure
- Flexible powering
- Dedicated 10G switch chip
The MikroTik GPERx6 delivers rugged, outdoor-ready networking — combining high-speed fibre uplinks with versatile power delivery in a single, compact unit. Built with a dedicated 10G switch chip and housed in a heavy-duty IP66-rated enclosure, it thrives in harsh conditions from –40 °C to +70 °C, making it ideal for remote deployments, industrial sites or perimeter surveillance setups.
The GPERx6 simplifies installations by merging data and power over one hybrid fibre-plus-copper cable: at the far end it splits into 3 × 10G SFP+ ports for long-distance uplinks, 3 × gigabit Ethernet ports (with one PoE-in and two PoE-out), and 3 DC outputs to support devices that don’t accept PoE.
With flexible power input (DC jack or PoE-in) and robust passive PoE-out and DC-out capabilities, it can power access points, cameras, IoT sensors or specialised equipment directly, eliminating the need for multiple power supplies or extra cabling. Thanks to its enterprise-grade switching performance and weather-proof build, the GPERx6 is a “set-and-forget” solution for demanding outdoor networking, delivering reliable performance and maximum deployment flexibility.
| Specifications | |
|---|---|
| Switch chip model | 88E6193X |
| Operating System | SwOS |
| MTBF | Approximately 200'000 hours at 25C |
| Tested ambient temperature | -40°C to 70°C |
| Powering | |
| Number of DC inputs | 2 (DC jack, PoE-IN) |
| DC jack input Voltage | 12-57 V |
| Max power consumption | 160 W |
| Max power consumption without attachments | 6 W |
| PoE in | 802.3 bt |
| Cooling type | Passive |
| PoE in input Voltage | 42-57 V |
| POE-OUT | |
| PoE-out ports | Ether2-Ether3 |
| PoE out | Passive PoE up to 57V |
| Low voltage PoE-Out current limit | 1.2 A |
| High voltage PoE-Out current limit | 0.625 A |
| Max total out (A) | 2.4 A |
| Total output power | 150 |
| Ethernet | |
| 10/100/1000 Ethernet ports | 3 |
| Number of 1G Ethernet ports with Reverse PoE (PoE-in) | 1 |
| Number of 1G Ethernet ports with PoE-out | 2 |
| Fibre | |
| SFP+ ports | 3 |
