Ubiquiti UniFi USW Flex 2.5G Compact 8 Port PoE Switch - USW-Flex-2.5G-8-PoE
Ubiquiti USW-Flex-2.5G-8-PoE
£177.59
Availability:Awaiting Date from Manufacturer
Linitx Quick Code # 18146
Manufacturer SKU: USW-Flex-2.5G-8-PoE
EAN: 810084695968
Manufacturer: Ubiquiti Inc
Categories:
| Quantity | 1+ | 10+ | 20+ | 50+ | 100+ | 250+ |
| Price | £147.99 EXC VAT | £146.51 EXC VAT | £145.03 EXC VAT | £142.81 EXC VAT | £140.59 EXC VAT | Call Us 01449 888000 |
||||UniFi Flex 2.5G PoE - USW-Flex-2.5G-8-PoE
At a glance:
- 8 x 2.5 GbE, PoE++ RJ45 ports
- PoE+++ in port PoE++ Type 4 90w
- 10G SFP+ / 10 GbE RJ45 combination port
The Ubiquiti UniFi Flex 2.5G 9 PoE is a flexible 8 port 2.5 GbE PoE++ switch with a 10 GbE RJ45/SFP+ combination uplink port that can be powered with PoE++ Type 4 (PoE+++) or an AC power adapter.
| Mechanical Specifications | ||
|---|---|---|
| Dimensions | 212.9 x 99.4 x 33.5 mm | |
| Weight | 567 g | |
| Enclosure material | Polycarbonate | |
| Mounting |
| |
| Hardware | ||
| Management interface | Ethernet In-Band | |
| Networking interface | (8) 2.5/1 GbE RJ45 ports (1) 10G SFP+ or 10/5/2.5/1 GbE RJ45 combination port* While only one is active, RJ45 can receive power and SFP+ can be utilized for data. | |
| PoE interface |
| |
| Total non-blocking throughput | 30 Gbps | |
| Switching capacity | 60 Gbps | |
| Forwarding rate | 44.64 Mpps | |
| Power method | (1) AC power adapter, 54V DC, 3.9A (Not included) (1) PoE+++ (PairA 1, 2+; 3, 6-)(PairB 4, 5+; 7, 8-) | |
| Power supply | External AC/DC adapter UniFi PoE switch | |
| Supported voltage range | AC/DC input: 54V DC (DC jack) PoE input: 50—57V DC | |
| Max. power consumption | PoE input: 14W (Excluding PoE output) AC input: 17W (Excluding PoE output) | |
| Total available PoE | PoE+++ input: 76W* PoE++ input: 46W* PoE+ input: 16W* 210W AC adapter input: 196W *Power values do not account for losses caused by cable length. | |
| Max. PoE wattage per port by PSE | PoE: 15.4W PoE+: 30W PoE++: 60W | |
| Voltage range PoE mode | PoE: 44—57V PoE+/PoE++: 50—57V | |
| Button | Factory reset | |
| Ambient operating temperature | -20 to 45° C | |
| Ambient operating humidity | 10 to 90% noncondensing | |
| Certifications | CE, FCC, IC | |
| Switching Features | ||
| Layer 2 features | STP / RSTP with priorities and port-level disable Storm control Multicast / broadcast rate limiting Flow control Jumbo frames Egress rate limit Proprietary loop protection Port isolation Port mirroring | |
| LEDs | ||
| System | Blue/white: power Blinking white: bootup in progress Blinking blue: firmware upgrading Steady white: factory defaults; unit is awaiting adoption Steady blue: unit is adopted | |
| Ethernet | Link/activity PoE input/output | |
| SFP+ |
| |
- USW-Flex-2.5G-8-PoE
- Wall Mount
PSU NOT INCLUDED - Recommend getting the UACC-Adapter-AC-210W
Please note that links to other websites are beyond our control. We link in good faith and are not be responsible for their content.
USW-Flex-2.5G-8-PoE Installation Guide
