Ubiquiti Enterprise Security Gateway - UXG-Enterprise

Ubiquiti Enterprise Security Gateway - UXG-Enterprise

At a glance:

• 12.5Gbps routing with IDS/IPS
• Shadow Mode (VRRP) Gateway Failover
• 2 x 2.5G RJ45 ports
• 2 x 10G SFP+ ports
• 2 x 25G SFP28 ports
• 2 x Included hot-swappable 150W PSUs
• Requires UniFi Network version 8.3.32 or later

Elevate your network’s backbone with the UXG-Enterprise, a high-capacity gateway purpose-built for demanding enterprise environments. Encased in a sleek 1U rack-mount chassis, it is powered by an 18-core ARM v8.2 processor running at 2 GHz and equipped with 16 GB of DDR4 memory, delivering formidable performance and headroom for growth.

Connectivity is abundant and future-proof: dual 25G SFP28 ports, dual 10G SFP+ ports, and dual 2.5 GbE RJ45 ports (two of which are remappable to WAN) allow for versatile deployments, aggregating multiple high-speed links or supporting multi-WAN load balancing. Designed to stand up to enterprise grade demands, the UXG-Enterprise supports up to 1 million concurrent sessions, 71,000 new sessions per second, and SSL/TLS inspection for up to 10,000 concurrent sessions.

Security features include: full stateful firewall, application-aware Layer 7 filtering, DPI, content and domain filtering, ad-blocking, signature-based IDS/IPS and license-free SD-WAN firmware come standard. High availability is built in via dual hot-swappable power supplies and VRRP (Shadow Mode) failover support, ensuring uninterrupted connectivity in mission-critical setups.

The UXG-Enterprise is designed to handle demanding throughput: firewall traffic up to 23.5 Gbps, IDS/IPS up to 12.5 Gbps, and high performance VPN and WireGuard support (for example, 1.2 Gbps for WireGuard and Teleport) for modern remote‐access and site-to-site requirements. With a compact footprint measuring 442.4 × 43.7 × 325 mm and weight of approximately 6.5 kg, it integrates easily into professional rack environments.

This gateway is fully aligned with UniFi’s unified management philosophy: it is compatible with the UniFi Network application (version 8.3.32 and later) and can be managed via UniFi CloudKey, UniFi Hosting or on-premise servers, allowing administrators to lever their existing tools and workflows.

The UXG-Enterprise brings enterprise-class connectivity, security and resilience into one integrated platform - ideal for service providers, data centres, and large-scale network deployments that demand high throughput, multi-WAN flexibility and full management integration.
