Ubiquiti UniFi Switch Pro HD 24 - USW-Pro-HD-24
Ubiquiti USW-Pro-HD-24
£569.99
Availability: Despatched next working day
Linitx Quick Code # 18148
Manufacturer SKU: USW-Pro-HD-24
Manufacturer: Ubiquiti Inc
Categories:
| Quantity | 1+ | 10+ | 20+ | 50+ | 100+ | 250+ |
| Price | £474.99 EXC VAT | £470.24 EXC VAT | £465.49 EXC VAT | £458.37 EXC VAT | £451.24 EXC VAT | Call Us 01449 888000 |
||||Ubiquiti UniFi Pro HD 24 Switch - USW-Pro-HD-24
At a glance:
- 2 x 10 GbE ports
- 22 x 2.5 GbE ports
- 4 x 10G SFP+ ports
The Ubiquiti UniFi Switch Pro HD 24 is a professional-grade, Layer 3 Etherlighting™ switch designed to enhance network performance. It features 22 Ethernet ports with 2.5 GbE connectivity, 2 Ethernet ports with 10 GbE connectivity, and 4 SFP+ ports offering 10G connectivity. The switch also includes Etherlighting™ ports that illuminate to indicate port location, speed/link status, and native VLAN/network.
| Mechanical Specifications | ||
|---|---|---|
| Dimensions | 442.4 x 285 x 44 mm | |
| Weight | Without mounting brackets: 4.2 kg With mounting brackets: 4.3 kg | |
| Enclosure material | SGCC steel | |
| Hardware Specifications | ||
| Management interface | Ethernet In-Band | |
| Networking interface | (2) 10/5/2.5/1 GbE, 100 MbE RJ45 ports (22) 2.5/1 GbE, 100/10 MbE RJ45 ports (4) 10/1G SFP+ ports | |
| Total non-blocking throughput | 115 Gbps | |
| Switching capacity | 230 Gbps | |
| Forwarding rate | 171.12 Mpps | |
| Power method | (1) Universal input, 100—240V AC, 50/60 Hz (1) USP-RPS DC input | |
| Power supply | AC/DC, internal, 60W | |
| Supported voltage range |
| |
| Max. power consumption | 50 W | |
| LCM display | 1.3" touchscreen | |
| Button | Factory reset | |
| Ambient operating temperature | -5 to 40° C | |
| Ambient operating humidity | 10 to 90% noncondensing | |
| Certifications | CE, FCC, IC | |
| Switching Features | ||
| Layer 2 features | IGMP snooping STP / RSTP with priorities and port-level disable Port isolation Storm control Voice VLAN Port mirroring LACP port aggregation Multicast / broadcast rate limiting MAC address blocking Flow control 802.1X control Jumbo frames Proprietary loop protection DHCP snooping / guarding Egress rate limit LLDP-MED Port restricted by MAC Device isolation with ACLs QoS Pro AV | |
| Layer 3 features | DHCP for locally-managed networks DHCP relay Inter-VLAN routing between networks on same switch Static routing between local networks Network isolation with ACLs | |
| Etherlighting™ | ||
| Ethernet | Locating Speed/link Native VLAN/network | |
| SFP+ | Locating Speed/link Native VLAN/network | |
| LEDs | ||
| System | Status | |
| RPS | Status | |
There is no box content detail for this product yet.
