Ubiquiti UniFi WAN Switch - USW-WAN
Ubiquiti USW-WAN
£238.79
Availability:Pre-Order Available
Linitx Quick Code # 18278
Manufacturer SKU: USW-WAN
Manufacturer: Ubiquiti Inc
Categories:
| Quantity | 1+ | 10+ | 20+ | 50+ | 100+ | 250+ |
| Price | £198.99 EXC VAT | £197.00 EXC VAT | £195.01 EXC VAT | £192.03 EXC VAT | £189.04 EXC VAT | Call Us 01449 888000 |
||||Ubiquiti UniFi WAN Switch SFP+ - USW-WAN
At a glance:
- High Availability* in Shadow Mode
- Output to Gateway 10G SFP+ (10G/1G)
- Output to redundant Gateway 10G SFP+ (10G/1G)
- Input from ISP 10G SFP+ (10G/1G)
- GbE MGMT port
- Dual AC Input - Redundant Power System
- Requires UniFi Network version 9.1.119 or later
The Ubiquiti USW-WAN WAN Switch is a specialised 10G SFP+ switch designed to link two UniFi Gateways operating in Shadow Mode High Availability (HA) to a single Internet Service Provider (ISP).
This setup ensures seamless failover and increased network resilience. The USW-WAN switches are recommended to maintain optimal performance and redundancy.
Key Features:
- High-speed 10G SFP+ connectivity
- Optimised for Shadow Mode HA configurations
- Compact design suitable for rack-mount installations
- Enhances network reliability and uptime
Ideal for enterprise environments requiring robust and reliable WAN connectivity, the USW-WAN ensures that critical network services remain uninterrupted during gateway failovers.
| Overview | |
|---|---|
| Dimensions | 442.4 x 120 x 43.7 mm |
Port Layout 1 GbE RJ45 10G SFP+ | 1
(1G/100M/10M) 3
(10G/1G) |
| Redundancy | (2) AC inputs |
| Form Factor | Rack mount (1U) |
| Performance | |
| Switching Capacity | 20 Gbps |
| Total Non-Blocking Throughput | 10 Gbps |
| Forwarding Rate | 15 Mpps |
| Hardware | |
| Max. Power Consumption | 13W |
| Power Method | (2) Universal input, 100—240V AC, 50/60 Hz |
| Power Input Method | AC input |
| Power Supply | (2) AC/DC, internal, 36W |
| Supported Voltage Range | 100—240V AC |
| Management | Ethernet |
| Weight | Without mounting brackets: 2.2 kg (4.85 lb) With mounting brackets: 2.3 kg (5.1 lb) |
| Enclosure Material | SGCC steel |
| Mount Material | SGCC steel |
| ESD/EMP Protection | Air: ± 16kV, contact: ± 22kV |
| Ambient Operating Temperature | -5 to 40° C (23 to 104° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
LEDs Ethernet SFP+ System | ✓ ✓ ✓ |
| Certifications | CE, FCC, IC |
| NDAA Compliant | ✓ |
| Software | |
Application Requirements UniFi Network | Version 9.1.119 and later |
There is no box content detail for this product yet.
